Honeywell · Handheld computer

Honeywell EDA5S

The Honeywell ScanPal™ EDA5S is an enterprise-class mobile computer that provides secure connectivity between frontline workers and backend business systems. It is designed for rugged use in transportation & logistics and healthcare applications.

Operating systemAndroid Android 11, and upgradeable to Android 13 (Android 13 is pending for the confirmation from Qual comm…
Display5.5-inch
ScanningS0703; Imager; Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
Battery3060mAh; Li-Ion, 3.8 V, 3,060 mAh, removable 3060mAh Li-Ion, 3.8 V, 3,060 mAh, removable
SealingIP67
DropMultiple 1.2m (4ft) drop to concrete per MIL-STD 810G under room temperature

Datasheet at Honeywell Product page at Honeywell

Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps

Specifications

Camera Position: Front and Rear
Connectivity: Wi-Fi Wi-Fi & Cellular
Environment: Standard
Application: Field Service Retail T&L
Durability: 1.2m (4ft)
Features: A sleek and stylish finish Reliable and Rugged
Cameras: Yes
Dimensions: 159mm x 75 mm x 11.2mm (6.26 in x 2.95 in x 0.44 in)
Decode Capability: Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
Computer Wireless Communication: WLAN; WWAN; Bluethooth; NFC; GPS
Bluetooth Specifications: Bluetooth Class 5.1
WWAN Specifications: FDD-LTE: Bands 1, 2, 3, 4, 5, 7, 8, 9, 12, 13, 17, 19, 20, 25, 26, 28, 30, 66 GSM/EDGE: Bands 2, 3, 5, 8 TDD-LTE: Bands 38, 39, 40, 41 UMTS/HSPA+: Bands 1, 2, 4, 5, 6, 8, 9, 19
WLAN Specifications: Additional WLAN Features: 802.11 d/e/h/i/k/ r/u/w /v , 1X1 MU-MIMO WLAN (Wi-Fi Alliance certified):NEWLINEIEEE 802.11 a/b/g/n/ac WLAN Security: OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise) WLAN Supported EAP:NEWLINETLS, PEAP, TTLS, PWD, LEAP
GPS Specifications: Simultaneous receiver support for GPS, GLONASS, and BeiDou (WWAN Only)
Operating System Type: Android
Operating system: Android 11, and upgradeable to Android 13 (Android 13 is pending for the confirmation from Qual comm & Google).
Platform: ScanPal
RAM / storage options: 3 GB RAM/32 GB Flash; 4 GB RAM/64 GB Flash
Display resolution: 1440 x 720 High Definition
Scan Engine Range: 1D/2D
Scan Engine Model: S0703
Scan Engine Type: Imager
Scan range / decode distances: No Scanner Standard Range (0-1m)
Display size: 5.5-inch
Scan Range: FlexRange FR
Processor: Qualcomm Snapdragon SM6115, Quad high-performance Kryo cores 2.0 GHz +Quad low-power Kryo cores 1.8 GHz
Keyboard / keys: Touchscreen
Network: WLAN/WWAN
Keyboard / keys: Full Touchscreen
Battery / runtime: 3060mAh
Battery Types: Only for EDA5S
Battery / runtime: Li-Ion, 3.8 V, 3,060 mAh, removable
Storage temperature: -20°C to +70°C (-22°F to 158°F)
Operating temperature: -10°C to +50°C (-4°F to +122°F)
Humidity: 5% to 90% (non-condensing)
Cold Storage: -20°C to +70°C (-22°F to 158°F)
Tumble specification: 300 times at 0.5 m (1.64 ft)
Drop specification: Multiple 1.2m (4ft) drop to concrete per MIL-STD 810G under room temperature
Protection Ratings: IP67
Warranty Duration: One-year factory warranty
Brand: Honeywell
Industry: Retail
Connectivity: Wi-Fi|Wi-Fi & Cellular
Application: Field Service|Retail|T&L
Features: A sleek and stylish finish|Reliable and Rugged
WWAN Specifications: FDD-LTE: Bands 1, 2, 3, 4, 5, 7, 8, 9, 12, 13, 17, 19, 20, 25, 26, 28, 30, 66|GSM/EDGE: Bands 2, 3, 5, 8|TDD-LTE: Bands 38, 39, 40, 41|UMTS/HSPA+: Bands 1, 2, 4, 5, 6, 8, 9, 19
WLAN Specifications: Additional WLAN Features: 802.11 d/e/h/i/k/ r/u/w /v , 1X1 MU-MIMO|WLAN (Wi-Fi Alliance certified):NEWLINEIEEE 802.11 a/b/g/n/ac|WLAN Security: OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise)|WLAN Supported EAP:NEWLINETLS, PEAP, TTLS, PWD, LEAP
Scan range / decode distances: No Scanner|Standard Range (0-1m)
X: BRV900~51400955-100
Operating temperature: -10°C to +50°C (+14°F to +122°F)
Storage temperature: -20°C to +70°C (-4°F to 158°F)
Operating temperature: -10°C to +50°C (+14°F to +122°F)
Storage temperature: -20°C to +70°C (-4°F to 158°F)

Manufacturer lists options and regional variants. Confirm selected SKU, delivered OS and scan engine.
