Honeywell · Handheld computer

Honeywell EDA56

ScanPal EDA56 WLAN is a Wi-Fi 6 mobile computer that provides higher data rates and lower latency even in highly dense connected environment. It is designed for use inside four walls in retail, manufacturing, logistics and public service applications

Operating systemAndroid Android 11, upgradeable to Android 13* Android 13 is pending for the confirmation from Qual- comm…
DisplayGorilla Glass 5, 5.5-inch
ScanningHoneywell S0703 Slim Imager; 1D/2D barcode
Battery4,500 mAh; Li-Ion, 3.8 V 4,500 mAh Li-Ion, 3.8 V
SealingIP67
DropMultiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperatureMultiple 1.5m (5ft) per MIL-STD…

Datasheet at Honeywell Product page at Honeywell

Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps

Specifications

Camera Position: Front and Rear
Connectivity: Wi-Fi Wi-Fi & Cellular
Environment: Standard
Application: retail, manufacturing, logistics, and public service
Cameras: 13-megapixel color front camera; 5-megapixel color rear camera
Dimensions: 159mm x 75 mm x 14.4 mm (6.26 in x 2.95 in x 0.57 in)
Decode Capability: 1D/2D barcode
Computer Wireless Communication: NFC: Integrated Near Field Communication
Bluetooth Specifications: Bluetooth Class 5.1
WLAN Specifications: (Wi-Fi certified): IEEE 802.11 a/b/g/n/ac/ax ,2*2 MU-MIMO WLAN Security: OPEN, WEP, WPA/WPA2/WPA3 (Personal and Enterprise) WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compliant
GPS Specifications: Simultaneous receiver support for GPS, GLONASS and BeiDou (WWAN Only)
Operating system: Android 11, upgradeable to Android 13* Android 13 is pending for the confirmation from Qual- comm and Google
Platform: ScanPal
RAM / storage options: 4 GBRAM/64 GB Flash; 6 GB RAM/128 GB Flash
Display resolution: 1440 x 720 High Definition
Scan Engine Model: Honeywell S0703 Slim Imager
Scan range / decode distances: Standard Range (0-1m)
Display size: Gorilla Glass 5, 5.5-inch
Processor: Qualcomm Snapdragon SM6115, Quad high-performance Kryo cores 2.0 GHz +Quadlow-power Kryo cores 1.8 GHz
Keyboard / keys: Full Touchscreen
Battery / runtime: 4,500 mAh
Battery Types: removable
Battery / runtime: Li-Ion, 3.8 V
Storage temperature: -30°C to +70°C (-22°F to 158°F)
Operating temperature: -20°C to +50°C (-4°F to +122°F)
Humidity: 5% to 90% (non-condensing)
Cold Storage: -30°C to +70°C (-22°F to 158°F)
Tumble specification: 550 times at 0.5 m (1.64 ft)
Drop specification: Multiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperatureMultiple 1.5m (5ft) per MIL-STD 810G drops with rubber boot concrete at room temperature
Protection Ratings: IP67
Warranty Duration: One-year factory warranty
Brand: Honeywell
Industry: Retail
Connectivity: Wi-Fi|Wi-Fi & Cellular
WLAN Specifications: (Wi-Fi certified): IEEE 802.11 a/b/g/n/ac/ax ,2*2 MU-MIMO|WLAN Security: OPEN, WEP, WPA/WPA2/WPA3 (Personal and Enterprise)|WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compliant
Operating system: Android 11, upgradeable to Android 13*|Android 13 is pending for the confirmation from Qual- comm and Google
X: BRV900~51400955-100

Manufacturer lists options and regional variants. Confirm selected SKU, delivered OS and scan engine.

Lifecycle

Sales status: Current catalogue
Status basis: Listed in official model catalogue; regional orderability requires confirmation.
