Honeywell · Tablet

Honeywell EDA10A

The Honeywell ScanPal™ EDA10A tablet is a lightweight solution to provide fast, reliable mobile data access on a 10-inch screen. Featuring Wi-Fi 6, it is designed for retail, warehouse and field service.

Operating systemAndroid * Android 14 is pending for the confirmation from Qual comm & Google. Android 12, and upgradeable to…
Display10.1 Inch, Gorilla Glass 5
ScanningS0703; Imager; Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
Battery8000mAh
SealingIP65
DropMultiple 1.3 m (4.3 ft) drop to concrete per MIL-STD-810H under room temperature|With protective boot…

Datasheet at Honeywell Product page at Honeywell

Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps

Specifications

Cameras: Yes
Camera Position: Front and Rear
Connectivity: Wi-Fi Wi-Fi & Cellular
Environment: Standard
Application: Field Service Retail Warehouse
Features: Lightweight (674g), yet durable and high performance Wi-Fi 6
Dimensions: 257 mm L x166.5 mm H x 11.7 mm W (10.12 in x 6.56 in x 0.46 in)
Decode Capability: Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
Computer Wireless Communication: WLAN; Bluethooth; NFC;
Bluetooth Specifications: Bluetooth Class 5.1/2.1 + EDR Class 2 (Bluetooth LE)
Operating System Type: Android
Operating system: * Android 14 is pending for the confirmation from Qual comm & Google. Android 12, and upgradeable to Android 14*
Platform: ScanPal
RAM / storage options: 4 GB RAM/64 GB Flash 8 GB RAM/128 GB Flash
Connection Interface: 6-PIN bottom connection USB 3.0 with Type-C interface
Display resolution: 1920 x 1200 Full High Definition
Scan Engine Range: SR
Scan Engine Model: S0703
Scan Engine Type: Imager
Scan range / decode distances: No Scanner Standard Range (0-1m)
Display size: 10.1 Inch, Gorilla Glass 5
Processor: Qualcomm Snapdragon SM4350-AC, Octa-Core, up to 2.2GHz
Keyboard / keys: Touch Screen Only
Network: WLAN
Keyboard / keys: Full Touchscreen
Battery / runtime: 8000mAh
Battery Types: Hot-swappable Li-Ion, 8,000 mAh, 3.85 V Removable
Storage temperature: -30°C to +70°C (-22°F to 158°F)
Operating temperature: -20°C to +50°C (-4°F to +122°F)
Humidity: 5% to 95% (non-condensing)
Drop specification: Multiple 1.3 m (4.3 ft) drop to concrete per MIL-STD-810H under room temperature With protective boot, multiple 2.0 m (6.6 ft) drop to concrete per MIL-STD-810H under room temperature
Protection Ratings: IP65
Warranty Duration: One-year factory warranty
Industry: Aerospace Healthcare Logistics & Warehouses Manufacturing Retail
Connectivity: Wi-Fi|Wi-Fi & Cellular
Application: Field Service|Retail|Warehouse
Features: Lightweight (674g), yet durable and high performance|Wi-Fi 6
Operating system: * Android 14 is pending for the confirmation from Qual comm & Google.|Android 12, and upgradeable to Android 14*
RAM / storage options: 4 GB RAM/64 GB Flash|8 GB RAM/128 GB Flash
Connection Interface: 6-PIN bottom connection|USB 3.0 with Type-C interface
Scan range / decode distances: No Scanner|Standard Range (0-1m)
Battery Types: Hot-swappable|Li-Ion, 8,000 mAh, 3.85 V|Removable
Drop specification: Multiple 1.3 m (4.3 ft) drop to concrete per MIL-STD-810H under room temperature|With protective boot, multiple 2.0 m (6.6 ft) drop to concrete per MIL-STD-810H under room temperature
Industry: Aerospace|Healthcare|Logistics & Warehouses|Manufacturing|Retail
X: BRV900~51400955-100
Operating temperature: (-4°F to +122°F)
Storage temperature: (-22°F to 158°F)
Ports / interfaces: Interface Ports: 6 PIN bottom connection
Operating temperature: (-4°F to +122°F)
Storage temperature: (-22°F to 158°F)
Ports / interfaces: Interface Ports: 6 PIN bottom connection

Manufacturer lists options and regional variants. Confirm selected SKU, delivered OS and scan engine.

Lifecycle

Sales status: Current catalogue
Status basis: Listed in official model catalogue; regional orderability requires confirmation.
