CAEN RFID · Accessory
CAEN RFID RHML37XEVB
The RHML37XEVBX Evaluation Board enables quick evaluation and development with Hadron mini R1271C, Lepton 3 R3100C and Lepton 7 R7100C. It provides an easy way to communicate with the readers via USB-UART or an arbitrary UART host and provides easy access to the inputs and outputs of the device.
Specifications
Specifications
- Digital I/O
- Four I/O lines 5V out @ 3mA, 5V input
- USB Port
- USB micro female connector USB 2.0 device It appears as dual Virtual COM Port device; drivers for all Windows OS
- DC power port via USB Port
- USB micro female connector
- External antenna connector
- SMA jack
- Embedded antenna
- Ignion NN01-105
- Raspberry PI interface
- HAT connector
- Electrical Power
- DC Voltage 5V +/-5%
- Current consumption
- 1.5A max. (with reader module)
- LED display
- GREEN: power from AC/DC adapter and/or USB port GREEN: reader module’s HEALTH YELLOW: reader module’s STATUS GREEN: GPIO[0..3]
- Dimensions
- (W)79 x (L)78 x (H)23 mm 3 (3.1 x 3.1 x 0.9 inch 3 )
- Operating temperature
- -20 °C to +70 °C
