Alien Technology · Accessory
Alien Technology GT
The “GT” is a 30mm x 50mm RFID inlay form-factor especially suitable for hang-tags. This tag is specifically designed for high read performance in the retail and apparel markets where items are tightly packed on shelves or hangers.
- DropPer ASTM D5276
Specifications
Specifications
- File
- Action
- ALN 9828 W (GT W) Datasheet (2020 01 22)
- Download
- ALN 9728 (GT) Datasheet (2016 07 05)
- Download
- Arkansas Radio Compliance Certification
- Download
- Over Antenna
- 0.06mm
- Over Antenna
- 0.16mm
- Over Antenna
- 0.08mm
- Antenna Width
- 1.970” [50mm]
- Antenna Length
- 1.180” [30mm]
- Web Width (-R)
- 2.460” [62.50mm]
- Web Width (-SR)
- 2.110” [53.50mm]
- Core Width (-R)
- 2.460” [62.50mm]
- Core Width (-SR)
- 2.110” [53.50mm]
- Recommended Storage
- +77ºF [+25°C] @ 40% RH
- Storage Limits
- -13°F to 122°F [-25°C to +50°C] 20% to 90% RH Non-condensing
- Drop specification
- Per ASTM D5276
- Inlay Width
- 2.090” [53.0mm]
- Inlay Length
- 1.300” [33.0mm]
- Web Width
- 2.210” [56.2mm]
- Core Width
- 2.210” [56.2mm]
- Adhesive Application Temperature
- > +25ºF [-4ºC]
- Adhesive Service Temperature
- -40ºF to +200ºF [-40ºC to +93.3ºC]
- Protocols Supported
- ISO/IEC 18000-6C GS1 Class 1 Gen 2
- Operating Frequency
- 840–960 MHz
- User Memory
- 128 Bits
- Recommended Storage
- +77ºF [+25°C] @ 40% RH
- Storage Limits
- -13°F to 122°F [-25°C to +50°C] 20% to 90% RH Non- condensing
- Drop specification
- Per ASTM D5276
- Adhesive Application Temperature
- > +25ºF [-4ºC]
- Adhesive Service Temperature
- -40ºF to +200ºF [-40ºC to +93.3ºC]
- Protocols Supported
- ISO/IEC 18000-6C EPCglobal Class 1 Gen 2
- Operating Frequency
- 840–960 MHz
- User Memory
- 128 Bits
- RF operating frequency
- 860-960 MHz
- RF operating frequency
- 840–960 MHz
- EPC memory
- Up to 128 EPC bits
- User memory
- 128 User bits
- Unique TID memory
- 48-bit Unique TID
- Unique TID memory
- 48 bit Unique TID
- Password memory
- 32 bit Access and 32 bit Kill passwords
- RF operating frequency
- 840-960 MHz
- RF operating frequency
- 840–960 MHz
- EPC memory
- 128-EPC Bits
- User memory
- 128 User Bits
- Unique TID memory
- 64 Bit Unique TID
- Password memory
- 32 Bit Access and 32 bit Kill Passwords
